Shaper Heads

Description

Shaper Heads

Shaper heads for molders, also called cutter heads, are the rotating tool that holds interchangeable knives or cutters on a woodworking molder or shaper. Shaper heads cut decorative profiles, edges, and complex shapes like door frames, crown molding, or cabinet trim onto wood for producing consistent, high-quality millwork.

These heads mount onto a vertical spindle. Swap knives out quickly to create different profile, using straight knives or profiled knives for curved finishes.

Compatible with Leading Molder & Shaper Brands

Williams and Hussey offers a specialized head that allows their proprietary knives (normally used in W&H molders) to be mounted on other brands of molders or shapers. This shaper head for molders acts as a compatibility bridge between W&H knives and non-W&H machines (Extrema, Weinig, Wadkin, SCMI, Mikron, US Concepts).

Knives must be drilled to accept 3/8″ bolts. Standard 4″ and 6″ shaper heads are manufactured with a 1-1/4″ bore. Shaper heads with larger bore sizes can be quoted upon request.

Available Shaper Head Sizes

• WH-404:  4″ Diameter × 4″ Length

• WH-406:  4″ Diameter × 6″ Length

• Standard bore: 1-1/4″

• Knife Mounting: Accepts knives with 3/8″ bolt holes

• Optional: Larger bore sizes available upon request

Why Chose Williams & Hussey Knives?

Our knives are highly regarded for quality, especially among woodworking professionals, known for their robust M2 high-speed steel, precision fit in their own machines for clean cuts, easy setup, and exceptional durability, allowing for high-quality profiles and historical restorations.

Williams & Hussey knives produce professional-caliber finishes, handle various wood types, and allow for quick, fuss-free setup, making them a benchmark for molding operations.

All of our machines and knives are designed and built in the USA, with a strong focus on quality control and long-term support.
