206 W&H MOLDER, Variable Feed: 208/230V, Single Phase **50 HZ (FOR EXPORT)** - 2 WEEK LEAD TIME
The W&H Model 206 (50Hz) is our export molder for customers with 50 HZ power requirements. This model is the most versatile and is ideally suited for customers looking to produce high quality moldings from a variety of millable material. This model features variable feed and multi-pass capabilities. This provides an unbeatable combination that ensures a smooth, clean molding finish.
*** FREIGHT CHARGE WILL BE QUOTED AFTER RECEIPT OF ORDER. ***
| Model Number: | 206.208/230.1.50 V2.5 |
| Feed Type: | 0-19 fpm, variable feed |
| Knife Motor: | 2 HP (3450 rpm) (50Hz Export) |
| Voltage: | 208/230V (50Hz Export) |
| Phase: | 1 |
| Arbor RPM's: | 6900 |
| Machine Base: Stationary |
Heavy Gauge Steel Construction: 24”L x 24”W x 33”H |
| Guide System: | 23 1/2"L x 11 3/4"W x 1/2"H, HDPE |
| MOLDER SPECS: | |
| Maximum Profile Depth ¾” | Maximum Height Above Final Cut 3⁄16” |
| Maximum Profile Width 6 ¾” | Maximum Stock Thickness 7” |
| Minimum Stock Length 9” | Planes 7” Wide |
| Minimum Stock Thickness ¼” | |
| Overall Machine Dimensions: | 24”L x 24”W x 50”H |
| Working Height: | 35” |
| Package Weight: | 315 lbs |
