209 W&H MOLDER, Variable Feed: 115V, Single Phase - 2 WEEK LEAD TIME
The W&H Model 209 is the best option for customers looking for a portable molder or homeowners limited to 115V power. Same as Model 206, the 209 also features variable feed and has multi-pass capabilities. This provides an unbeatable combination that ensures a smooth, clean molding finish.
Model Number: | 209.115.1 V2.5 |
Feed Type: | 0-19 fpm, variable feed |
Knife Motor: | 1-1/2 HP (3480 rpm) |
Voltage: | 115V (20 AMP REQUIRED) |
Phase: | 1 |
Arbor RPM's: | 6960 |
Machine Base: Stationary |
Heavy Gauge Steel Construction: 24”L x 24”W x 33”H |
Guide System: | 23 1/2"L x 11 3/4"W x 1/2"H, HDPE |
MOLDER SPECS: | |
Maximum Profile Depth ¾” | Maximum Height Above Final Cut 3⁄16” |
Maximum Profile Width 6 ¾” | Maximum Stock Thickness 7” |
Minimum Stock Length 9” | Planes 7” Wide |
Minimum Stock Thickness ¼” | |
Overall Machine Dimensions: | 24”L x 24”W x 50”H |
Working Height: | 35” |
Package Weight: | 315 lbs |
Shipping Information: | The freight charge quoted is subject to change. Additional taxes, duties, and charges are possible if shipped out of the United States. |
